Section 4: Advanced Configuration 16
Basic Tab
Be sure to click Apply once you have made changes.
Forwarding Tab
Click ADD to create additional Port Forwarding rules.
Be sure to click Apply once you have made changes.
Port Forwarding Basic Tab Fields
Field or Button Description
Enable UPnP IGD Enables Universal Plug and Play (UPnP)
Internet Gateway Device (IGD) profile to
allow certain Windows applications to setup
the port forwarding rule dynamically when
NAT is enabled on this device.
DMZ IP Address Enter the DMZ IP Address.
Forwarding Tab Fields
Field or Button Description
Select Select a box when you want to delete the
specific row.
Protocol Select TCP (Transmission Control Protocol)
or UDP (User Datagram Protocol).
WAN Port Start Enter the beginning port range for external
network access.
WAN Port End Enter the ending port range for external
network access.
LAN IP Address Enter the IP address to host the service in
the dotted-decimal format.
LAN Port Start Enter the beginning port range for internal
network access.
LAN Port End Enter the ending port range for internal
network access.
Enabled Check to enable specific port forwarding.
