8
Test-Um NT955 Series
Test Ports and Cable Adapters
Validator-NT is equipped with four dedicated ports for testing data,
telephone, coax, and 2-wire cable types.
Data Jack RJ45 8-wire data interface
Telephone Jack RJ11, 6-wire Telco interface
USOC pairing
Coaxial Connector “F” connector coax interface
Banana Jacks 2-wire testing
The Validator-NT test kit is supplied with five cable assemblies designed
to connect to the data, telephone, coax, and 2-wire ports of the main or
remote Validator-NT units. A set of 8 wiremap remotes (TP610) are also
included in this test kit.
TP74 4” sacrificial cable with RJ45 connectors
TP20 7.5” no fault cable assembly with RJ11
connectors for the RJ11 or RJ45 port
TP55 12” shielded cable assembly with RJ45 connectors
TP68 24” cable assembly with an RJ45 connector and 8
alligator clips
TP62 Adapter, BNC plug to F jack
Note: It is recommended that you leave the TP74 Sacrificial Cables
connected to prolong the life of the RJ45 network cable port of your
Validator-NT main and remote unit.
