Tripp Lite SNMP Solo MT-SE-37/02 - Manual (Page 23)

Tripp Lite
Configuration 17
Figure 8 Trap Receivers
To set traps, at the prompt type:
Set, <space>, enter the number of the column from 1 through 4,
<space>, enter the IP address, <space>, severity code–1,2, or
3, and name of the community string. Press . The
severity level codes for messages are:
• 1 Informational
• 2 Warning
• 3 Severe
The trap receiver receives all assigned severity level messages
and the ones rated above. If you assign severity code 2, the
manager receives warning and severe levels.
A set trap example.
The top of the screen reflects your changes:
