Television system NTSC standard
Channel coverage VHF: 2 through 13
UHF: 14 through 69
Cable TV: mid band (A-8 through A-1, A through I)
super band (J through W)
hyper band (AA through ZZ, AAA, BBB)
ultra band (65 through 94, 100 through 125)
Power source 120V AC, 60Hz
Power consumption 32A32: 94W (average)
32A42: 94W (average)
32A42A: 102W (average)
36A42:
109 W (average)
Audio power 5W + 5W
Speaker type 2-3/8 x 4-3/4 inches (60 x 120 mm)
Audio/Video terminals S-VIDEO INPUT
Y-INPUT: 1V (p-p), 75 ohm, negative sync.
C-INPUT: 0.286V (p-p) (burst signal), 75 ohm
AUDIO/VIDEO INPUT
VIDEO: 1V(p-p), 75 ohm, negative sync.
AUDIO: 150mV(rms) (30% modulation equivalent, 47k ohm)
ColorStream ® (component video) INPUT
Y: 1V (p-p), 75 ohm
C
R
(P
R
): 0.7 V (p-p), 75 ohm
C
B
(P
B
): 0.7 V (p-p), 75 ohm
AUDIO/VIDEO OUTPUT
VIDEO: 1V(p-p), 75 ohm, negative sync.
AUDIO: 150mV(rms) (30% modulation equivalent, 4.7k ohm)
Dimensions 32A32: Width 30-3/8 inches (772mm)
Height 28 inches (711mm)
Depth
22-1/2 inches (572mm)
32A42/32A42A: Width 34 inches (864mm)
Height 27-1/2 inches (699mm)
Depth
21-1/8 inches (537mm)
36A42: Width 38-3/16 inches (970mm)
Height 30-1/16 inches (764mm)
Depth
25-1/4 inches (641mm)
Mass 32A32: 111 lbs (50,3kg)
32A42/32A42A: 111 lbs (50,3kg)
36A42:
154 lbs (69,9kg)
Supplied accessories Remote Control with 2 size “AA” batteries
Optional TV stand 32A32: ST3232
32A42/32A42A: ST3242
36A42:
ST3642
Design and specifications are subject to change without notice.
