CONTROL LOCATIONS
FRONT VIEW
1. Camera Lens Open
16. CD Door 32. REPEAT Button
Button 17. MIC Holder 33. PROGRAM Button
2. Adjustable Camera Lens 18. Release iPod Buckle 34. AUTO VOICE CONTROL
19. iPod Docking Station 35. RANDOM Button 3. 7" TFT LCD Color Screen
36. SKIP Button 20. iPod dock Releaser 4. ON/OFF Button
37. BALANCE Control 5. ON/OFF LED 21. MIC 1 Jack
38. SKIP Button 6. TUNING Knob 22. HEADPHONE Jack
39. STOP Button
7. Dial Pointer 23. LCD ADJ. Buttons
40. PLAY/PAUSE Button 8. BAND Selector 24. Model Number
41. OPEN/CLOSE Point 9. Monitor Selector 25. PROGRAM LED
42. MASTER VOLUME 10. Video Out Selector 26. LED Display
Control 11. Function Selector 27. PLAY/PAUSE LED
43. iPod Compartment 12. Key Control LEDs 28. MIC VOLUME Control
44. MIC Holder 13. Key High 29. CDG LED
45. MIC 2 Jack 14. Key Flat 30. REPEAT LED
15. Key Low 31. ECHO Control
