Data Sheet: Veta  iHA48040A033V*, 3.3V/40A Output Half Brick Series
©2007 TDK Innoveta Inc.
iHA Datasheet 040207
' (877) 498-0099
3/17
Ordering information:
Product
Identifier
Package Size Platform
Input
Voltage
Output
Current/
Power
Output
Units
Main
Output
Voltage
# of
Outputs
Safety
Class
Feature Set
i H A 48 060 A 033 V - 0 00
TDK Innoveta Half Brick Veta

36-75V 60 Amps 033 – 3.3V Single
00 – Standard
OVP: Over Voltage Protection; OCP: Over Current Protection; OTP: Over Temperature Protection.
Product Offering:
Code Input Voltage Output Voltage Output Current
Maximum Output
Power
Efficiency
iHA48060A012V-000 36V to 75V 1.2V 60A 72W 83%
iHA48060A015V-000 36V to 75V 1.5V 60A 90W 86%
iHA48060A018V-000 36V to 75V 1.8V 60A 108W 86.5%
iHA48060A025V-000 36V to 75V 2.5V 60A 150W 89%
iHA48060A033V-000 36V to 75V 3.3V 60A 198W 90%
iHA48040A033V-000 36V to 75V 3.3V 40A 132W 90%
iHA48060A050V-000 36V to 75V 5.0V 60A 300W 90%
iHA48040A050V-000 36V to 75V 5.0V 40A 200W 91%
iHA48025A120V-000 36V to 75V 12.0V 25A 300W 91.5%
iHA48013A240V-000 36V to 75V 24.0V 12.5A 300W 91%
iHA48011A280V-000 36V to 75V 28.0V 11A 308W 91%
iHA48016A280V-000 40V to 60V 28.0V 16A 450W 93.5%
TDK Innoveta Inc
3320 Matrix Drive, Suite 100
Richardson, Texas 75082
Phone (877) 498-0099 Toll Free
(469) 916-4747
Fax (877) 498-0143 Toll Free
(214) 239-3101
[email protected]
http://www.tdkinnoveta.com/
Feature
Set
On/Off
Logic
Omit
pin3
Output OVP Output OCP OTP
Threaded
Inserts
Pin
Length
00 Positive No Latching Auto-Recovery Auto-Recovery Yes 0.145”
01 Negative No Latching Auto-Recovery Auto-Recovery Yes 0.145”
02 Positive Yes Auto-Recovery Auto-Recovery Auto-Recovery Yes 0.145”
03 Negative Yes Auto-Recovery Auto-Recovery Auto-Recovery Yes 0.145”
04 Positive No Latching Auto-Recovery Auto-Recovery Yes 0.110”
05 Negative No Latching Auto-Recovery Auto-Recovery Yes 0.110”
06 Positive Yes Auto-Recovery Auto-Recovery Auto-Recovery Yes 0.110”
07 Negative Yes Auto-Recovery Auto-Recovery Auto-Recovery Yes 0.110”
