2-7 Operation
2.5.2 TPA751 MSOP Audio Power Amplifier Evaluation Module Parts List
Table 2–2 shows the TPA751 EVM parts list.
Table 2–2. TPA751 EVM Parts List
Reference Description Size
EVM
Qty.
Manufacturer/
Part Number
Vendor
Number
C4 Capacitor, 10
µ
F, 6.3 V A 1 Panasonic
ECS-TOJY106R Digi-Key
PCS1106CT-ND
C1, C2,
C3, C5 Capacitor, 1
µ
F, 80%/–20%,
nonpolarized
0603 4 Murata
GRM39-Y5V105Z10PT Newark
R1, R3, R4 Resistor, 20 k
Ω
, 1/16 W, 5% 0603 3 Panasonic
ERJ-3GSYJ203 Digi-Key
P20KGCT-ND
R2, R5 Resistor, 39 k
Ω
, 1/16 W, 5% 0603 2 Panasonic
ERJ-3GSYJ393 Digi-Key
P39KGCT-ND
S1 Switch, momentary 1 Panasonic
P8048SCT-ND Digi-Key
P8048SCT-ND
Terminal Post Headers 9 Sullins
PTC36SABN Digi-Key
S1022-36-ND
U1 IC, TPA751DGN † , audio
amplifier, 700 mW, mono
MSOP-8 1 TI
TPA751DGN
PCB1 PCB, TPA751 MSOP EVM 1
† Due to the very small size of the MSOP IC package, the standard part number TPA751 is replaced with the code TIATC.
Note: All items are SMD except as noted.
