Installation Notes:
• Contractor Rac Pro mounts onto the side rails of your truck without drilling.
• Installation is straight forward, and should take approximately 45 minutes to complete.
1. Verify that you have received the correct parts using the assembly drawing and packing list.
Contractor Rac Pro
2. Install the cleat using two bolts (3/16” Allen
Wrench). Loosely attach bottom of the corner
braces to all four uprights using hex bolt
(16mm socket).
Table 1. Tools Required
1) Socket Wrench
2) 13mm, 15mm, 16mm
and 17mm Sockets
3) 5mm Allen Wrench
4) 3/16” and 5/16”
Allen Wrench
Recommended
1) Torque Wrench
Figure 2. Cleat and Corner Brace installation.
Figure 1. Contractor Rac Pro Installed on a truck bed.
Item
No.
1
2
3
4
5
Qty.
1
2
1
1
1
Table . Cleat and Corner Brace Parts
Description
Cleat
Bolt 1/4-20X1.75
Corner Brace
Hex Bolt,
M10-1.5X25
Heavy Washer,
M10, THICK
Part No.
PI-11009
HD-80136
01-22008
HD-23143-1
HD-23193
1
UPRIGHT
2
3
4 5
Contractor Rac Pro INSTRUCTION MANUAL 7 TracRac Inc. 994 Jefferson Street, Fall River, MA 02721-4893 • 800-501-1587
Figure 13. Upright Parts.
Item
No.
1
2
3
4
5
6
Qty.
1
2
1
1
2
2
Table 7. Upright Part Reference
Description
Cleat
Bolt 1/4-20X1.75”
Nut Bar
Spacer, Cantilever
Bushing, Oval Tube
Hex Flange Bolt, M8X1.25, 50mm
Part No.
PI-11009
HD-80136
FX-11139
PI-23327
FX-90138
HD-23163-1
Figure 14.
Cantilever
Clamp Parts.
Item
No.
1
2
3
4
Qty.
1
1
1
4
Table 8. Cantilever Clamp Part Reference
Description
Cantilever Clamp
Label, TracRac
Lock Nut M10X1.5
Bolt, M10X1.5, 35mm Hex
Part No.
01-11144
BL-22000-D
HD-23179
HD-23165
Figure 15. Forward
Bracket Parts.
Figure 16. Tie Down Kit.
Item
No.
1
2
3
Qty.
1
1
2
Table 9. Forward Bracket Part Reference
Description
Nut Bar
Bracket, Forward
Bolt, M8X1.25, 16mm Hex Flange
Part No.
FX-11139
01-11142
HD-23163
Item
No.
1
2
3
Qty.
2
2
2
Table 10. Tie Down Kit Part Reference
Description
Tie Down Zinc Diecast
Knob, Female 3/8-16 UNC
T-Bolt #3/8-16X1-1/8, SS
Part No.
10-25111
KB-90004
HD-80122
NOTES: Although the Contractor Rac is capable of carrying a maximum of 1250 lbs, evenly distributed between both racks,
the capability is limited to the strength of the truck sidewall it is mounted on. More information on back cover.
