TracRac IM TracTonnuea User Manual
Tracrac, inc. limited warranty

TOOLS REQUIRED:
1. 9/16” Ratchet or Wrench
2. Large Flat Screwdriver
3. 1/8” Allen Wrench
13 ___*___
Black Bow
14 1702992
Spring Plunger, 5/8" x 1.94"
15 1703260
Tension Control Bracket
16 1703345
Spring Pin, 1/8" x 5/16"
17 ___*___
Shur-Bond™ VELCRO
®
Fasteners
18 1703332
Hitch Pin, 1/16" x 1 5/16"
19 1703643
Set Screw, 1/4” x 3/8”
20 ___*___
Side Rail, Passenger’s Side
21 ___*___
Side Rail, Driver’s Side
22 1114773
Flat Spring, 5/8" x 3 7/8"
23 1703650
Latch Main Frame
24 1702610
Clevis Pin, 3/16" x 1 1/4"
1
___*___
TracTonneau Replacement Cover
2
___*___
Black Header
3
___*___
Header Seal, Notched
4
1115372
Header End Plugs (Set of Two)
5
1702602
Square Nut, 3/8"
6
1115354
Header Insert Safety Clip
7
___*___
Safety Strap
8
1114872
Header Guide
9
1703000
Cap Screw, 3/8" x 1 1/2"
10 1115353
Header Safety Strap
11 1703344
Blind Rivet, 1/8" x 3/16"
12 1701595
End Plug, 1" OD
25 1703639
Toggle
26 1700419
Nylon Lock Nut, 5/16"
27 1703265
Toggle Cap
28 1702611
Cotter Pin, 3/64" x 19/32"
29 1702926
Cap Screw, 5/16" x 7/8"
30 1702801
Header Stop
31 1703301
Side Rail End Plug, Left
32 1116263
Side Rail End Seal, 3”
33 1703300
Side Rail End Plug, Right
34 1116265
Side Rail Cab Seal, 4 1/2”
35 1116264
Side Rail Top Gap Seal, 2 5/8”
* Please specify length or make and model of vehicle.
TRACRAC REPLACEMENT PARTS
3
33
3
3”
1
2
3
6
5
4
8
9
11
10
7
2
13
19
18
17
33
14
15
16
20
21
3
31
30
29
23
22
28
25
27
24
26
12
P/N 1116240 Rev
A
34
32
35
