SPECIFICATIONS
Overall Dimensions
Width 17-1/2” (445mm)
Depth (inc. rear cord clearance, peel removed) 28” (711mm)
Depth (inc. rear cord clearance, peel in toaster) 32” (813mm)
Height (inc. legs) 10-1/2” (267mm)
Toasting Area Dimensions
Width, Loading Area of Peel 11-1/4” (286mm)
Length, Loading Area of Peel 16-1/2” (419mm)
Vertical Clearance Above Peel in Toasting Chamber 1-3/4” (44mm)
Toaster Information
Approximate Net Wt. 58.0 lbs. (26.3kg)
Approximate Shipping Wt. 69.4 lbs. (31.5kg)
Construction Formed and welded sheet steel
Finish Stainless steel
Pre-Heat Time 15 minutes
Normal Product Load 12 muffin halves or 6 bagel halves
Capacity 720 muffin halves per hour
Electrical Specifications
Operating Voltage Model MBT208: 208V
Model MBT240: 230V or 240V
Frequency 50/60Hz
Phase 1 Ph
kW Rating Model MBT208: 2.45kW at 208V
Model MBT240: 2.45kW at 230V
2.67kW at 240V
Current Draw Model MBT208: 11.8A at 208V
Model MBT240: 10.7A at 230V
11.1A at 240V
Cord and Plug Information USA & standard export:
3-wire cord (2 hot, 1 gnd), #12 AWG, with 30A pin-and-sleeve plug
OR
3-wire cord (2 hot, 1 gnd), #12 AWG, with 30A twist-lock plug
OR
HO7RN-F harmonized cord with 3x4,0mm conductors
and 30A twist-lock plug
Europe:
HO7RN-F harmonized cord with 3x4,0mm conductors
and 32A pin-and-sleeve plug
OR
HO7RN-F harmonized cord with 3x4,0mm conductors
and 16A pin-and-sleeve plug (Germany MBT240 only)
