• LED display for easy status monitoring
• Superior video resolution - up to 1920x1440;
DDC,DDC2,DDC2B
System Requirements
Console
• A VGA, SVGA, or Multisync monitor capable of the
highest resolution that will be used on either of the
computers
• A USB keyboard
• A USB mouse
• Speakers and microphone with 3.5mm plug
(optional for audio)
Computers
Each PC must have:
• A VGA, SVGA, or Multisync port
• A USB port(s) for a keyboard and a mouse
• Speaker and microphone port with a 3.5mm plug
(optional for audio)
3
This package should consist of:
• 1 B034-002-R KVM Switch
• 1 User Manual
Table of Contents
Features....................................................................p. 2
System Requirements ..............................................p. 3
Components ............................................................p. 4
Hardware Installation ..............................................p. 4
Operation ................................................................p. 5
Specifications ..........................................................p. 7
Certification/Warranty ............................................p. 8
Features
• Control two USB computers from a single USB
console (monitor, USB mouse and USB keyboard)
• Share speakers between systems
• Built-in cables (6 ft. long)
• Supports Microsoft Intellimouse, Logitech
FirstMouse+, MouseMan+, and others
• Convenient Hot Keys for fast port selection right
from the keyboard
• USB keyboard & mouse emulation for error-free
booting
• Hot pluggable - add or remove computers without
powering off the KVM switch
• Plug-n-Play monitor support
• AutoScan mode for monitoring computers
• Easy to install - No software required, no installation
routines
2
