21
Model Series 410 & 420
Ref
No.
Part Number Description
1 681-0133 Tongue Hitch Mount
2 681-0134A Base Hitch Mount
3 710-3001 Hex Cap Screw, 3/8-16 x.88
4 711-0299 Clevis Pin,.625 x 2.4
5 711-0835 Clevis Pin,.50 x 4.62
6 712-04065 Flange Lock Nut, 3/8-16
7 732-0194 Spring Pin
8 736-0133 Flat Washer,.411 x 1.25 x 1.0
9 681-04006† Upper Chipper Chute Assembly
10 681-04007† Lower Chipper Chute Assembly
11 710-0106† Hex Cap Screw, 1/4-20 x 1.25
12 710-3013† Screw, 1/4-20 x .50
13 712-3010 Hex Nut, 5/16-18
14 712-04064† Flange Lock Nut 1/4-20
15 714-0104† Cotter Pin
16 728-0175† Pop Rivet
17 732-0306A† Compression Spring,.531 x 1.75
18 735-0249A† Chute Flap
19 736-0140† Flat Washer
20 736-0242 Bell Washer.340 ID x.872 OD
21 736-0451 Washer,.320 ID x.93 OD
Ref
No.
Part Number Description
22 747-04163† Lock Rod
23 749-1004† Chipper Chute Support
24 781-04032† Chipper Chute Hinge
25 781-0633† Chute Flap Strip
26 710-0805 Hex Cap Screw, 5/16-18 x 1.50
27 749-04104 Tube Support
28 681-0184A†† Frame Assembly
681-0183A† Frame Assembly
29 710-0502A Hex Sems Screw, 3/8-16 x 1.25
30 736-0170 Special Lock Washer, 5/16
31 726-0214 Push Cap, 5/8
32 634-04009 Wheel, 10 x 4 x 4
33 750-0786 Spacer, .64 x .88 x .38
34 738-0813 Axle, 22.47”
35 737-0195 Elbow Fitting
36 726-0233† Push Nut,.25ID x.50OD
37 681-0095†† Chipper Chute
38 712-04063 Flange Lock Nut, 5/16-18
— 664-04023* Debris Collection Bag
— 723-0400* Safety Glasses
† Model Series 420
††
Model Series 410
* Not Shown
