Troy-Bilt 420 - Manual (Page 19)

19
† Model Series 420
††
Model Series 410
Model Series 410 & 420
Ref
No.
Part Number Description
1 681-04094 Impeller Assembly Complete
2 710-1054 Machine Screw, 5/16-24 x 1.0
3 738-04286 Shoulder Pin, .5 x 2.625
4 712-0411 Hex Lock Nut, 5/16-24
5 712-0266A Nut, Jam Lock, 3/8-16
6 719-04308 Flail Blade
7 736-0119 Lock Washer, 5/16
8 742-04050 Shredder Blade
9 742-0544 Chipper Blade
10 711-0835 Clevis Pin,.50 x 4.62
11 736-0217 Lock Washer, 3/8
12 736-0247 Flat Washer,.406 x 1.25
13 710-1254 Hex Cap Screw, 3/8-24 x 2.2
14 736-0242 Bell Washer.340 ID x.872 OD
15 681-04011 Shredder Hopper Assembly
16 710-0809 Hex Cap Screw, 1/4-20 x 1.250
17 712-04065† Flange Lock Nut, 3/8-16
18 712-04063 Flange Lock Nut, 5/16-18
19 732-04167† Torsion Spring
20 736-0182† Spring Washer,.50 x 1.0 x.022
21 736-0326† Flat Washer,.50 x 1.0 x.0125
22 738-0430† Shoulder Screw, 3/8-16,.50 x.685
Ref
No.
Part Number Description
23 749-04103 Hopper Handle
24 781-04007 Shredder Plate
25 781-04027 Hopper Support Bracket
26 781-04033 Inlet Guide
27 681-0117 Inner Flail Housing Assembly
28 681-04002 Outer Flail Housing Assembly
29 710-0157 Hex Cap Screw, 5/16-24 x.75
30 710-0825 Hex Cap Screw, 1/4-20 x 3.75
31 710-3025 Hex Cap Screw, 5/16-18 x.625
32 726-0211 U-Nut, 5/16-18
33 736-0119 Lock Washer, 5/16
34 750-0793 Hinge Spacer,.265 x.380 x 1.66
35 681-0048 Knob Ass’y. (Incl. ref.# 14 & 40)
720-0170 Knob Only, 5/16-18
36 681-0094 Chute Deflector Assembly
37 714-0149B Internal Cotter Pin
38 719-04070 Shredder Screen
39 736-0173 Flat Washer,.28 x.74 x.063
40 726-0201 Speed Nut,.3125ID
41 712-04064 Nut, Flange, Lock, 5/16-18
42 710-0599 TT Screw, 1/4-20 x.5
