Troy-Bilt TB465SS User Manual
Page 47
E19
BOOM AND TRIMMER PARTS - MODEL TB465SS
4-CYCLE GAS TRIMMER
TB465SS PARTS LIST
Item Part No.
Description
1
753-04234
Throttle Housing Assembly (includes 2-4)
2
791-182405
Switch
3
753-04119
Throttle Trigger
4
791-182690
Throttle Trigger Spring
5
753-05166
Drive Shaft Housing Assembly (includes 8)
6
791-153064
D-Handle (includes 7)
7
791-181587
D-Handle Hardware Assembly
8
753-05167
Flexible Drive Shaft
9
791-153597
Lower Clamp Assembly (includes 13)
10
791-180547
Guard Mounting Screw Assembly
11
791-180548
Guard Assembly (includes 12)
12
791-180553
Blade Assembly
13
791-145569
Anti-Rotation Screw
14
753-05168
Gearbox Assembly (includes 15 & 16)
15
753-05165
Fixed HD Line Assembly (includes 16 & 17)
16
791-153066B Bump Head Knob Assembly
17
791-182413
Lock Washer
Optional Accessories
*
753-01564
Replacement Line
*
Items Not Shown
1
1
3
4
6
7
8
9
11
12
13
14
12
10
15
16
2
1
5
17
