E18
BOOM AND TRIMMER PARTS - MODEL TB415CS
4-CYCLE GAS TRIMMER
TB415CS PARTS LIST
Item Part No. Description
1 753-04234 Throttle Housing Assembly (includes 2-4)
2 791-182405 Switch
3 753-04119 Throttle Trigger
4 791-182690 Throttle Trigger Spring
5 753-05162 Drive Shaft Housing Assembly
6 791-153064 D-Handle (includes 7)
7 791-181587 Handle Hardware
8 753-04282 Guard Mounting Hardware
9 753-04283 Guard (includes 10)
10 791-180553 Blade Assembly
11 753-05165 Fixed Line Head (includes 12 & 13)
12 791-182413 Lock Washer
13 791-153066B Bump Head Knob Assembly
Optional Accessories
* 753-05164 Replacement Line
* Items Not Shown
1 1
6
5
4
3
9
13
11
8
10
1
7
8
2
12
