Technicolor - Thomson CP-2016-007 - Manual (Page 21)

16
Aura SoHo™ Conference Phone
Order Information: Part Number CP-2016
Features
Certifications: FCC part 68, UL, CE, VCCI, A-TICK, RoHS compliant
Telephone connection: Analog PBX or standard analog PSTN line
Digital PBX Modules: Available, support 100s of PBXs
Microphone: 3 Noise cancelling 360° coverage, 44 dB ± 4 dB
sensitivity, 200 Hz- 3.3 kHz
Speaker/Amplifier: Output >95 dB at 5 watts,
Bandwidth 200 Hz - 3.3 kHz
Operating Temperature: 32-122° F ( 0-50° C)
Storage: Temperature: -20-85 degree C
Controls and Interfaces
Buttons:
Power, 0 to 9 number keys, * and #, Volume Up/Down, Mute, Redial,
Flash, Hold, Conference Now™
LED Indicators:
Power, Mute On
Operating Mode:
Full Duplex with noise and echo cancellation, using
DSP from Acoustic Technologies
Electrical Specifications
Power: 100~240V AC 1A Max 50~60Hz
Microphone Sensitivity: 44 dB ± 4 dB, 200 Hz- 3.3kHz
Loudspeaker Volume: >95dB at 5 watts, Bandwidth 200 Hz- 3.3 kHz
Certifications: FCC part 15 Class A, UL, A-Tick, Canadian, VCCI, RoHS
Physical Specifications
Aura SoHo™: 8” (20.3cm) dia. x 1.5” (3.81 cm) height
Weight: 1 lb. 10 oz (740 gm)
Inputs/Accessories
Connection Input: RJ-11 for phone; RJ-45 for Aura SoHo™
Conference Phone to Wall Mounted Adapter; RJ22 4 pin for
external microphone; Multi-pin connector for optional Adapter
Modules (Digital, Bluetooth®, Wireless), RCA connector for
monitoring or recording
Included Accessories: AC Wall Mounted Adapter, 6’ (1.83m) cord;
RJ-11 phone cord 6’ (1.83m); RJ-45 network cable 16’ (4.87m)
Optional Accessories for Accessory Bay:
Bluetooth® Module, PBX for Digital Phone Systems, Wireless
SPECIFICATIONS
