Disconnect the telescopic tube from the hose and the

●

nozzle or brush.
In case of vacuuming or picking up water with the use

●

of the water fi lter module, remove the dirty water from

the tank.
It is recommended to wash the container, fi lters

●

(disassembly below) and partition thoroughly after each

use – changing water several times.

ATTENTION! If you do not clean the above-mentioned

parts or clean them insuffi ciently it may lead to the loss

of the fi ltration capabilities of the inserts and foam and

cause the formation of bacteria and mites.

Dry all the cleaned parts thoroughly before reassembly.

Filter disassembly

FOAM FILTER I

1 Open the lid of the fi lter unit – press the handle and lift

the lid.

2 Take out the fi lter, wash it under running water, dry and

reinsert.

Close the fi lter unit lid by pressing it until you hear

●

a characteristic click.

FOAM FILTER II
It is recommended to wear rubber protective gloves while

dismantling the fi lter.

1 Grab the foam fi lter with your fi ngers and remove it from

the fi lter unit body.

2 Wash under running water, dry and reinsert.
ATTENTION! Do not hand wash the fi lter foam, do not

wring it, do not wash it in washing machines. Avoid

crumpling, stretching and deforming. After cleaning

dry the foam in room temperature. Never dry the foam

on heaters, stoves, etc.

INLET FILTER

1 Press the “PRESS” button and remove the tank lid.
2 Remove the SAFBAG (25) dust bag module from the

container.

3 Take out the SAFBAG dust bag from the module (see

chapter TRADITIONAL CLEANING WITH SAFBAG DUST

BAG – disassembly/assembly of the SAFBAG dust bag).

4 Release the fastening hook which fi xes the lid of the

SAFBAG dust bag module with the basket and pull the

basket aside.

5 Take out the fi lter, wash it under running water, dry and

reinsert.

6 Close the basket of the SAFBAG dust bag module by

pressing it until you hear a characteristic click.

7 Insert SAFBAG dust bag (see chapter TRADITIONAL

CLEANING WITH SAFBAG DUST BAG – disassembly/

assembly of the SAFBAG dust bag).

8 Insert the dry fi ltration module with the SAFBAG (25)

dust bag into the tank.

Insert and snap the tank lid shut.

●

MOTOR FILTER
A fi ltration fabric is inserted in the motor cooling cycle which

is to catch the coal dust which arises due to the natural wear

and tear of the brushes and the commutator in the motor.

1 Remove the tank from the vacuum cleaner.
2 Place the vacuum cleaner with the “wheels upwards” so

that the upper sloping surface and the handle are rested on

the fl oor. Insert a fl at, narrow tool e.g. a screwdriver into the

special slot of the fi lter lid; pry the fastening with an upward

hand movement (lever principle) which will release the lid

latch while being bent.

3 If the motor fi lter (8) is dirty, it is possible to rinse the

fi lter (8) under running water. Remember to dry the above

mentioned fi lter before reassembly.

4 Insert the new/rinsed motor fi lter (8), make sure that the

fi lter edges do not remain outside the outline of the section.

Snap the fi lter lid shut by fi rst inserting the lower fastening

and then pressing the fastening so that the upper fastening

clicks into place at the edge of the appliance body.

OUTLET HEPA FILTER AND FOAM FILTER III
The HEPA outlet fi lter should be replaced after about 30

hours of operation (6 months) or earlier in case of heavy dirt.

1 Remove the tank from the vacuum cleaner.
2 Place the vacuum cleaner with the “wheels upwards” so

that the upper sloping surface and the handle are rested on

the fl oor.

3 Slide the slider of the fi lter cover interlock to the “open”

position and remove the fi lter lid.

4 Remove the foam fi lter III (11). Rinse or replace if the

fi lter becomes dirty. Remember to dry the fi lter before

reassembly.

5 Remove the foam fi lter III (11) and next remove the HEPA

fi lter by grabbing the handle. Replace with a new one if the

fi lter becomes dirty.
It is recommended to periodically inspect the condition of the

fi lter, especially if there was a water overfl ow to the outside of

the vacuum cleaner. In case of detecting damage (a break)

in the fi lter layer or if the layer is evenly covered with dust,

the fi lter should be replace with a new one.

6 If the HEPA fi lter is dirty, replace it with a new one or

rinse under running water. Remember to dry the fi lter before

reassembly.

7 Reinsert the fi lters, insert the fi lter lid and press fi rmly.
8 Slide the slider of the fi lter cover interlock to the “closed”

position.
Turn the vacuum cleaner to its natural position (on four

wheels).
