7. Speaker Preset Setting
Recalls speaker EQ preset values for specific TOA model speakers. 9000Series Amplifier
responds with the same data as that received.
Note: Command cannot be received during power off.
ADH, 02H, ,
00H - 07H (Output channel 1 - 8)
SPEAKER PRESET TABLE
Value Sense (dB) Value Sense (dB)
HEX DEC HEX DEC
00H 0 ALL FLAT 08H 8 H-3 SUB WOOFER
01H 1 F-122 09H 9 HB-1
02H 2 F-122 SUB WOOFER 0AH 10 FB-100
03H 3 H-1 0BH 11 SW FOR F-122
04H 4 H-1 SUB WOOFER 0CH 12 SR-S4 SINGLE
05H 5 H-2 0DH 13 HX-5_E
06H 6 H-2 SUB WOOFER 0EH 14 HX-5_E_LOCUT
07H 7 H-3 0FH 15 FB-120
8. COMMAND LIST
Function Command Code
Channel fader gain 91H, 03H, , ,
(position)
93H, 03H, , ,
(step)
Crosspoint gain 95H, 05H, , Number>, , Channel Number>,
Preset memory recall F1H, 02H, 00H,
Terminate "EVENT" F1H, 02H, 01H,
