TOA Electronics RS-232C User Manual
Page 18
01H: Low Pass Filter
HIGH PASS FILTER
TABLE – 00H
LOW PASS FILTER
TABLE – 01H
Example: Setting the Input Channel 3’s High Pass Filter to 31.5 Hz.
A2H, 04H, 00H, 02H, 00H, 03H
5.10. Input Sensitivity Setting
Performs input sensitivity setting of Input channel. 9000Series Amplifier responds with the
same data as that received. Input sensitivity setting is enabled only for the channel on
which the D-001T or AN-001T is used.
Note: Command cannot be received during power off.
ACH, 02H,
00H - 07H (Input channel 1 - 8)
Page 18 of 24
Value
HPF (Hz)
HEX
DEC
00H
0
OFF
01H
1
20
02H
2
25
03H
3
31.5
04H
4
40
05H
5
50
06H
6
63
07H
7
80
08H
8
100
09H
9
125
0AH
10
160
0BH
11
200
0CH
12
250
0DH
13
315
0EH
14
400
Value
LPF (Hz)
HEX
DEC
00H
0
4k
01H
1
5k
02H
2
6.3k
03H
3
8k
04H
4
10k
05H
5
12.5k
06H
6
16k
07H
7
20k
08H
8
OFF
