18
TANDBERG FieldView Device User Guide D14041.02 January 2008
To end still image display:
Press the 1. Capture button.
Or
Tap the Camera icon at the top of the screen.
The Still Image Details screen appears.
Tap
2. End Still Image Display.
To share an image:
Make a call to a FieldView Application. 1.
Open the File Browser. 2.
Using the Folder and File panes, select the image you want to share. 3.
Tap 4. Share.
6.5. Configuration
To check or update FieldView Device configuration options:
1. Starting from the default Viewfinder display, press the Display button three
times to display the Main Menu.
2. From the Main menu, tap the Configuration menu option to display a
Configuration window.
From here, follow on-screen instructions to adjust the configuration options
as necessary. The table below is provided as an overview. Please see the
System Administration manual for detailed information on FieldView Device
configuration.
Tab Configuration Options Provided
General Adjust the standby timeout (amount of time before the
FieldView Device will switch from On to Standby, if it is idle).
Specify the location of saved images and video recordings,
and Still Image Capture button mode.
Display Adjust the brightness of the viewfinder backlight or
recalibrate the touch panel.
Video Adjust the video settings of the camera and select the video
source (internal camera or external via S-Video connector).
Audio Options for controlling volume and mute levels for the
speaker. You can set the maximum ring volume (the volume
will ramp up to this setting regardless of the overall volume
setting of the FieldView Device) and request voice/audio
reduced bandwidth usage. This screen can also be used
to select the source for subject audio—either the built-in
microphone or the Audio line in connector.
Network This screen allows you to adjust Network settings. Please
see the System Administration manual for detailed
instructions.
Radio Options to enable the radio and select radio channels.
SIP SIP server information necessary for registering this device.
Security This screen allows you to set default login options and
import security certificates.
Tabs on the Configuration window.
Still Image Details screen
