Configure Menu
Press the CONFIG button to open the Configure menu, which is shown in
Figures 2--5 through 2--7. The configuration parameters for the instrument are
grouped into functional submenus within the Configure menu. Use the general
purpose knob and/or the touchscreen to navigate within the menu.
CAUTION. To prevent a misadjustment of the instrument, do not use the adjust-
ment menu selections in the Calibration submenu without referring to the
WFM700 Series Service Manual (Tektronix, Inc. part number 071-0915-XX).
HELP
PRINT
FREEZE
DISPLAY
CONFIG
PRESET
General Alarms
RGB Gamut
Composite Gamut
Luminance Gamut
Video Signal Missing
Video Format Change
Serial Alarms
Configure Menu
Video Format Mismatch
Video--Ref Format Mismatch
Ext Ref Signal Missing
Ext Ref Format Mismatch
Input Signal not HD
RP165 EDH Status
RP165 FF CRC
RP165 AP CRC
SMPTE292 Y CRC
SMPTE292 C CRC
SDI Code Word Violation
SDI Line Length Error
SDI Field Length Error
SDI SAV Placement
292M Line Mismatch
Audio Alarms
(Option DG Audio
module only)
Emb. Audio Presence
AES Audio Unlocked
AES Audio Parity
Validity Bit
Professional CRC
Audio Mute
Audio Clip
Audio Silence
Audio Over
Emb. Group Sample Phase
Configure menu continues
in Figure 2--6
Configure Alarms
Auxiliary Alarms
Closed Caption Presence
Closed Caption Changes
Closed Caption Parity
Closed Caption Protocol
V-Chip Presence
V-Chip Rating Change
Anc Data Presence
Anc Data Parity
Anc Data Checksum
ARIB STD-B39 Presence
Physical Alarms
(WFM700M only)
Eye Amplitude
Eye Rise Time
Eye Fall Time
Eye Rise-Fall Delta
Eye Rise Overshoot
Eye Fall Overshoot
Jitter
Figure 2- 5: Configuration menu diagram - part 1
