General information
Table 2 - General data - RTCA
Unit size
108
109
111
113
115
116
Condenser
Condenser type
Aluminium fins/copper tubes
Fin spacing
(fins/ft)
168
168
144
168
168
144
Frontal surface area
(m²)
5.7
6.9
6.9
11.3
11.7
13.7
Airflow
Standard unit
(m
3
/h)
42500
50400
69300
77200
84700
98500
Low noise unit
(m
3
/h)
34500
40900
56300
62700
68800
80000
Condenser fans
Number of fans
4
4
6
8
8
12
Fan speed
Standard unit
(rpm)
690
Low noise unit
(rpm)
560
Nominal fan power
Standard unit
(kW)
0.85
Low noise unit
(kW)
0.54
Current fan amps
Standard unit
(A)
2.4
Low noise unit
(A)
1.2
Minimum Starting/
Operating Ambient (1)
(°C)
7 Standard units/-18 Low ambient units
Refrigerant
R134a
Number of Independent
Refrigerant Circuits
1
1
1
1
1
1
Refrigerant Charge
(kg)
22
26
36
44
52
72
Operating Weight (2)
(kg)
810
890
1090
1535
1770
2050
Shipping Weight (2)
(kg)
1020
1100
1300
1870
2170
2450
Hot gas connection
(inches)
1 5/8
1 5/8
1 5/8
1 5/8
1 5/8
1 5/8
Liquid connection
(inches)
1 1/8
1 1/8
1 1/8
1 1/8
1 1/8
1 1/8
Unit size
208
209
211
213
215
216
Condenser
Condenser type
Aluminium fins/copper tubes
Fin spacing
(fins/ft)
168
168
144
168
168
144
Frontal surface area
(m²)
5.7
6.9
6.9
11.3
11.7
13.7
Airflow
Standard unit
(m
3
/h)
42500
50400
69300
77200
84700
98500
Low noise unit
(m
3
/h)
34500
40900
56300
62700
68800
80000
Condenser fans
Number of fans
2 x 2
2 x 2
2 x 3
2 x 4
2 x 4
2 x 6
Fan speed
Standard unit
(rpm)
690
Low noise unit
(rpm)
560
Nominal fan power
Standard unit
(kW)
0.85
Low noise unit
(kW)
0.54
Current fan amps
Standard unit
2.4
Low noise unit
1.2
Minimum Starting/
Operating Ambient (1)
(°C)
7 Standard units/-18 Low ambient units
Refrigerant
R134a
Number of Independent
Refrigerant Circuits
2
2
2
2
2
2
Refrigerant Charge
(kg)
2 x 11
2 x 13
2 x 18
2 x 22
2 x 26
2 x 36
Operating Weight (2)
(kg)
810
890
1090
1535
1770
2050
Shipping Weight (2)
(kg)
1020
1100
1300
1870
2170
2450
Hot gas connection
(inches)
1 5/8
1 5/8
1 5/8
1 5/8
1 5/8
1 5/8
Liquid connection
(inches)
1 1/8
1 1/8
1 1/8
1 1/8
1 1/8
1 1/8
(1) Based on a 2.2 m/s wind across the condenser
(2) With aluminium fins
