Basic Functions cont. Software Version 4.01
Items marked SY are only available when the SY-88 is installed.
Function Display
LED
To Enter Function To Enter
Data
Remarks
17 Slave reference, Time Code or ABS
time ABS SY Press & or Press DISPLAY to exit
18 Digital or Analog output mode
selection Hold press Digital In - This sets a 43Fs delay on all 8 tracks for digital
dubbing. Display will exit automatically
19 Track Delay Hold press DISPLAY or Press Track Assign to select track to delay. Press
DISPLAY to exit
20 ALL Track Delay Hold press DISPLAY
then Hold Rec. for track 1
& press Rec. for track 2
or If no change is made, individual track delay values
are retained.
Press DISPLAY to exit
21 Crossfade Hold press DISPLAY or Press DISPLAY to exit
22 Shuttle Monitor Mode Hold press SHUTTLE or When ON this will mute all tracks not in Rec Ready
when in shuttle mode. Rec Ready tracks will switch
to Input. Press DISPLAY to exit
23 OFFSET Tally, On / Off Hold press CHASE or Press DISPLAY to exit
24 Punch In point Display & Modify MEMO 1 Perform Rehearsal or Press DISPLAY + to Exit or DISPLAY to go to
Punch out point
25 Punch Out point Display & Modify MEMO 2 Perform Rehearsal or Press DISPLAY + to Exit
26 Display Preroll and Enter or modify
data ABS Press & when
Rehearsal or Auto In LED
is blinking or On
or Press DISPLAY + to Exit
27 Greeting ABS In TEST mode Hold +
+ DISPLAY + and press
remote. Release
&
first then DISPLAY
or
and
DISPLAY
Use or to scroll through letters. Press
DISPLAY after each correct letter. Press &
when done to Exit message mode. Reboot.
28 Display Errors Any Press REMOTE button
when in TEST mode - Track Meters 1 & 2 show Block Error Rate in real
time for playback heads A & B
29 Enter SY-88 Menu System TC SY Press & - This enters the SY-88 Menu system
30 Exit SY-88 Menu System “ SY Hold DISPLAY press - This will exit SY-88 Menu system
31 Chase Record Enable ABS Hold press TC Rec
button
or Allows front panel Record command on slave units.
Must have SYS version.34.02
32 20dB or 16dB Headroom Select ABS Hold press ALL INPUT or Requires Modification & SYS ver 61.03
