Elo TouchSystems 2200L User Guide 16
On-Screen Display (OSD) Control Panel
The On-Screen Display (OSD) control panel is located on the side of
the monitor, as shown above.
OSD Control Buttons
The OSD control buttons allow you to change settings on the monitor
screen. The fi ve buttons shown above are:
OSD Menu Functions
The control buttons have the following functions:
MENU Displays or exits the OSD Menus
UP 1) Enters brightness and/or contrast of the OSD (if no
OSD is currently displayed on screen)
2) Increases value of OSD adjustment choice
3) Selects OSD choice counterclockwise
1 MENU
2 UP
3 DOWN
4 SELECT
5 POWER
1
2
3
4
5
