7
ENGLISH
pull it towards yourself (Picture 2). Remove
the lid (Picture 3). Take filters’ block out by
pulling the strips (Picture 4). Insert new fil-
ters’ block into the purifier: first insert its
upper part, afterwards it lower part. Close
the lid uniting the slots in purifier housing
with lugs on the lid.
Replacing UV-lamp
Make sure the appliance is disconnected
from the wall outlet before replacing UV-
lamp.
Take lower corners of the air inlets lid and
pull it towards yourself (Picture 2). Remove
the lid (Picture 3). Take filters’ block out by
pulling the strips (Picture 4).
Turn off the screws fastening the screen of
the lamp by screwdriver, remove the screen.
Carefully rotate the lamp for quarter of turn
in any direction, take the lamp out. Insert
new UV-lamp and rotate the lamp for quar-
ter of turn in any direction. Install the screen
of the lamp into its position. Install filters’
block. Close the lid of the purifier.
Trouble Shooting
Malfunction
Possible
causes
Elimination
Appliance
cannot be
switched on
1. Appliance is
not plugged
in the socket.
1. Insert the
plug into the
wall outlet.
2. There is no
power in the
wall outlet or
supply line.
2. In order to
test the sock-
et try to plug
any other
electric ap-
pliance in the
same socket.
3. Front lid of
filters’ block
are not in-
stalled prop-
erly.
3. Check out
if front lid of
filters’ block
are installed
properly.
4. Appliance
malfunction.
4. Apply to the
authorized
service center
for the appli-
ance repair.
High noise
level
1. Filter is dirty. 1. Replace filter.
2. Appliance
malfunction.
2. Apply to the
authorized
service center
for the appli-
ance repair.
Technical Specifications
Supply voltage: AC 220-240V, ~ 50 Hz
Power supply: 110 W
Noise level: 65 dB
Room capacity: 60 m2
Weight: 7.2 kg
Dimensions:
470*228*445 (mm)
Negative ions output: (at distance of 10 cm
from air outlet) 200mln/cm3
Carbonic acid absorption: (ppm – parts per
million) 95%
Operating conditions: environment tem-
perature -40 to +40°С
Relative humidity of the air less than 90%
Specifications subject to change without
prior notice.
MINIMUM SERVICE LIFE - 5 YEARS
GUARANTEE
Details regarding guarantee conditions can
be obtained from the dealer from whom
the appliance was purchased. The bill of
sale or receipt must be produced when
making any claim under the terms of this
guarantee.
This product conforms to the
EMC-Requirements as laid
down by the Council Directive
89/336/EEC and to the Law
Voltage Regulation (73/23 EEC)
