Tiger TWR-180 - Manual (Page 23)

-22- June 27, 2006
C310-820 Single Acting Wing Cylinder Kit
Includes Ref # 2 only.
Ref. Part No. Description Qty.
1 100-3701 Cyl. 3 X 12 ORB 2
2 108-056 Breather, filter 3/4- 16 ORB 2
3 108-043 Elbow, 3/4" ORB male X JIC male 2
4 111-185 Hose assembly, 3/8 SW, 183" long 2
5 C000-005 Restrictor 2
8 302-015 Clevis pin, 1 x 2-7/8 UL 2
9 256-001 Flat washer, 1 x 2 2
10 271-005 Cotter pin, 3/16 x 1-1/2 2
WING LIFT CIRCUIT, SINGLE ACTING
