Controls and features – Troy-Bilt HYDROSTATIC LAWN TRACTOR - HORSE 769-06304 User Manual
Page 12
Figure 4-1
Parking Brake Lever
Brake Pedal
Speed Control Lever
Cup Holder
Throttle/Choke Lever
Ammeter
Deck Lift Lever
PTO (Blade Engage) Lever
Ignition Switch
Module
Controls and Features
4
12
Lawn Tractor controls and features are illustrated in Fig 4-1 and described on the following pages.
WARNING!
Read and follow all safety rules and instructions in this manual, including the entire Operation section,
before attempting to operate this machine. Failure to comply with all safety rules and instructions may result in personal
injury.
