SPECIFICATIONS
AUDIO SECTION:
OUTPUT POWER
OUTPUT IMPEDANCE
2 WATTS + 2 WATTS (RMS)
8 OHMS
CD PLAYER SECTION:
FREQUENCY RESPONSE
SIGNAL - TO - NOISE RATIO
D - A CONVERSION
NUMBER OF PROGRAMS
SAMPLING SYSTEM
WOW AND FLUTTER
POWER SECTION AC 110V-120V~60Hz
DIMENSIONS (H x W x D) 7.6 x 14.1 x 8.2 Inches / 19.2 x 35.8 x 20.9 cm
WEIGHT 8.6 lbs / 3.9 kgs
Specifications are typical, individual units might vary. They are subject to continuous
improvement without notice and without incurring any obligation.
MICROPHONE
-74 dB 600OHMS IMPEDANCE WITH
6.3mm DYNAMIC MICROPHONE Æ
MONITOR SECTION
5.5” BLACK AND WHITE TV MONITOR
NTSC SYSTEM
220 LINE RESOLUTION
ACCESSORIES
1. PRE-RECORDED KARAOKE CD+G DISC
2. AV CABLE
3. DYNAMIC MICROPHONE
100 Hz - 20 kHz (+/-3 dB)
50 dB
1 BIT D/A CONVERTER
20 TRACKS PROGRAM MEMORY
8 TIME OVER SAMPLING
IMMEASURABLE
E17
ENGLISH
RADIO SECTION:
AM FREQUENCY RANGE
FM FREQUENCY RANGE
530-1710 kHz
88-108 MHz
