29
(E) 1520DL75
Using the PC setting feature
You can adjust picture position, clock, phase, Auto configure, and
reset as you prefer.
1. Press TV/VIDEO repeatedly to select PC input mode. (See
“Selecting the video input source” in page 20.)
2. Press MENU, and then press x or • until the PC menu appears.
3. Press z, and then press y or z to select reguired item.
H-Position 76
ENTER EXIT MENU
H-Position
V-Position
Clock
Phase
Auto configure
Reset
PC
4. Press Enter.
5. Press
x or • to make appropriate adjustments.
• H-position/V-position
Adjusts picture left/right and up/down. The adjustment ranges
of H-Position is 0–100. (Based on the input mode, the
adjustable range may change.)
• Clock
Minimizes any vertical bars or stripes appearing on the screen
background. The adjustment ranges is 0–100. (Based on the
input mode, the adjustable range may change.)
• Phase
Reduces (or Minimizes) any horizontal noise and clear up or
sharpen the character images. The range adjustment is 0–100.
(Based on the input mode, the adjustable range may change.)
• Auto configure
Automatically adjusts the screen position, clock, and clock
phase. (The displayed image will disappear for a few seconds
while Auto-configu-ration is in progress.)
• Reset
Returns to the default settings programmed at the factory;
default settings cannot be changed.
6. Press ENTER to save.
CH
CH
RECALL TV/VIDEO
MUTE POWER
MTS
ENTER
CC EXIT MENU
SLEEP SOUND PICTURE
FAV. CH
VOL VOL
2 1 1 3
5 4 6
8 7
0
9
100/
CH RTN C
yzx •
MENU
ENTER
TV/VIDEO
TV top panel
POWER TV/VIDEO VOLUME CHANNEL
TV/VIDEO
