FEATURE DISPLAY
PARAMETER
SETTINGS
COMMENT
Encryption Key
Loading
Menu item: KEYLOAD
Once selected:
KEY LOAD BANK = N
Up to 8 banks of 7 keys
Enables the radio to accept the loading of encryption
keys.
Display Current
Encryption
Key(s)
Menu item: DISP KEY
Once selected:
SYS KEY, GRP KEY or
CHN KEY and KEY = N
Displays current encryption key number.
Scan Menu item: SCAN ON, OFF Toggles scan function ON or OFF.
Private Mode
Menu Item: PRIVATE
Once selected: PVT or key
light.
ON, OFF Toggles private function ON or OFF.
Scan Add
Menu item: SCAN ADD
Once selected: Proper scan
icon displayed.
S, 2 or 1 Adds group or channel to scan list.
Scan Delete
Menu item: SCAN DEL
Once selected: Scan icon goes
out.
Deletes group or channel from scan list.
Scan Add/Delete
Menu item: SCAN A/D
When selected: Toggles
through scan selections
Toggle sequence
S, 2, 1, S, ... Changes present group or channel to next scan choice
in scan list.
Last Scanned
Channel Recall
Menu Item: SCAN ADD
Press twice when actively
receiving; three times when not
receiving. Scan icon displayed.
Changes the selected channel to the last scanned
channel.
Home group or
channel selection
Menu item: HOME
Once selected: Home group or
channel displayed.
Changes to the group or channel defined for Home
function.
System select
Menu item: SYS SEL
Once selected: SYS = n 1-64 = (n)umber of
desired system
Displays the system selected.
External alarm #2 Menu item: EXTALRM2 ON, OFF Toggles external alarm #2 feature ON or OFF.
System and group
selection
Menu item: SYSGRP 1
Menu item: SYSGRP 2
Menu item: SYSGRP 3
Menu item: SYSGRP 4
Menu item: SYSGRP 5
Changes to the System & Group/Channel
programmed for SYSGRP 1-5.
Mute Menu item: MUTE ON, OFF
Toggles the mute function ON or OFF to control the
audio output from the selected radio.
Mute #1 Menu item: MUTE 1 ON, OFF Toggles the mute 1 function ON or OFF on radio #1.
Mute #2 Menu item: MUTE 2 ON, OFF Toggles the mute 2 function ON or OFF on radio #2.
Multiple radio
operation
Menu item: RADIO ON, OFF Toggles the currently selected radio.
Menu item: RADIO 1 ON, OFF Changes to radio #1.
Radio selection
Menu item: RADIO 2 ON, OFF Changes to radio #2.
No Data Menu item: NO DATA ON, OFF Toggles data feature ON or OFF.
EDACS Convent-
ional Priority 1
Scan
Menu item: ECP1SCAN ON, OFF Toggles this feature ON or OFF.
Group selection
Menu item: GRP SEL
Once selected: GRP = n 1-64 = (n)umber of
desired group
Displays the group selected.
Status Condition
Menu item: STATUS Once
selected: ST =n 0-9 = (n)umber of pre-
programmed status
Transmits the pre-programmed status message.
Message
Condition Menu item: MESSAGE
Once selected: MSG =n 0-9 = (n)umber of pre-
programmed messages
Transmits the pre-programmed message.
Feature
Encryption
Display
Menu Item: FEATURES
Once selected:
See Feature Encryption
Display section
Informational displays
only; no user selectable
settings
Indicates current features program- med into the radio
as well as certain information required to add features
to the radio (refer to the Table of Contents for Feature
Encryption Display.
System Scan
Enable
Menu Item: SYS SCAN
Once selected: SYSC ON or
SYSC OFF
ON, OFF
System Scan features like ProScan are toggled ON
and OFF.
