2.2 Easy Installation
2.2.3 Channel Search
You can search the channels.
If you press the
OK button, the Installation screen will appear
If you want to search the channel, you select between Satellite and
Terrestrial. And then press the
OK button to move to the channel
search setting screen.
2.2.4 Satellite - Channel Search
Select the satellite you want using the UP/DOWN buttons on the
satellite list.
Ƈ To Edit or Add satellite list
• To edit or add satellite list on the list, press the YELLOW button to
select edit or add mode. And press the OK button.
• Place the cursor on satellite field and press the OK button.
• The keypad will be displayed so that you can Edit or Add satellite
name you want.
• Input degree you want using the NUMERIC buttons or the
LEFT/RIGHT buttons. And press the OK button to save.
Ƈ To Delete satellite list
• To delete satellite list on the list, press the YELLOW button to select
delete mode. And press the OK button.
Ƈ To Edit, Add, or Delete TP list
• When the GREEN button is pressed, it can be toggled Satellite list and
TP list.
• Press the YELLOW button to edit, add or delete the TP list.
• Input Mode, Frequency, Symbol Rate, Polarity, and FEC, and press the
OK button to save.
Ƈ TP Search
Press the RED button on the TP list.
Pop up window will be displayed on the screen.
•
Frequency : Input a proper Frequency using the NUMERIC
buttons.
• Symbol Rate : Input a proper Symbol Rate using the NUMERIC
buttons.
• Polarity : Use the LEFT/RIGHT buttons to select the
Polarisation of the transponder.(Horizontal, Vertical)
• FEC : Use the LEFT/RIGHT buttons to select the FEC of the
transponder.
• You can select the value of Auto, 1/2, 2/3, 3/4, 5/6, and 7/8.
•
Network : You can select Yes or No. When you select “Yes”,
you can find more transponders using the home
network.
• Video PID/Audio PID/PCR PID :
You can set PID to search for services.
Use the LEFT/RIGHT buttons or the NUMERIC
buttons to input the value.
Press the OK button to start Scanning.
