Overview Datacryptor Ethernet User Manual
Page 14 THALES
Figure 3-3: Thales Datacryptor 1 Gig Ethernet Front Panel
Figure 3-4: Datacryptor 1 Gig Ethernet Rear Panel
Figure 3-5: Thales Datacryptor 10 Gig Ethernet Front Panel
Figure 3-6: Datacryptor 10 Gig Ethernet Rear Panel
Note: See The Front Panel LEDs in the Element Manager Reference section for full
information on the LED indicators.
