TU 500 EXERCISE BIKE
REF.
# PART # DESCRIPTION QTY
2 7T010800 FRONT STABILIZER WITH BOLTS 1 SET
3 7T000200 TRANSPORTATION WHEEL HIT 1 SET
4 7T000300 FTONT STABILIZER END CAP 2 PCS
5 7T000400 CRANK PULLEY WITH CAPS AND BEARINGS 1 SET
6 7T000600 BOLT BELT TENSION
1 PC
7 7T010900 BRAKE ASSY 1 SET
8 7T001700 ALUMINUM IDLER ASSY 1 SET
9 7T001800 ECB DC MOTOR WITN SCREWS 1 SET
10 7T002000 ECB CONTROL BOARD WITH SCREWS 1 SET
11 7T001900 ECB LIMIT SWITCH WTH SCREWS 1 SET
^12-
1 7T011000 LEFT SHROUD WITH DECALS 1 SET
^12-
2 7T001302 SCREW 1 PC
^12-
3 7T001202 SCREW 6 PCS.
^12-
4 7T001303 SCREW 3 PCS.
^12-
5 7T011100 RIGHT SHROUD WITH DECAL 1 SET
^12-
6 7T001306 HEX NUT SIDE COVER 3 PCS.
^12-
7 7T011200 DECAL---WHITE----RIGHT 1 PC
^12-
8 7T001311 SHROUD DECAL B WHITE 1 PC
^12-
9 7T001312 SHROUD DECAL D WHITE 1 PC
^12-
10 7T011300 DECAL---WHITE----LEFT 1 PC
^12-
11 7T001308 SHROUD DECAL-A WHITE 1 PC
^12-
12 7T001309 SHROUD DECAL C WHITE 1 PC
13 7T001400 PEDALSET WITH STRAPS 1 SET
14 7T004000 HANDLE BAR 6 PIN WITH BOLTS 1 SET
14-
1-1 7T004001 CABLE ASSY 6 PIN UPPER
1 PC.
14-
1-2 7T004002 CABEL ASSY 5 PIN UPPPER
1 PC.
15 7T004100 BOTTLE CAGE WITH SCREWS 1 SET
16 7T001100 COMPUTER WITH SCREWS 1 SET
17 7T003800 DC JACK 1 PC
18 7T003900 ADAPTER 9VDC 1.2A 1 PC
19 7T004200 CD PLAYER HOLDER WITH SCREWS 1 SET
20 7T004300 SEAT ADJUSTING KNOB 1 PC
21 7T000900 SHROUD TRIM CAP 1 PC
22 7T004400 SEAT POST SLEAVE 1 PC
23 7T004500 SEAT POST 1 PC
24 7T004600 SADDDLE WITH CLAMP 1 PC
Page 25
