E6581281 f
- 31 -
3.7. Control Supervisor Object
Class code 0x29. This object models all the management functions for devices within the DeviceNet
“Hierarchy of Motor Control Devices”. The behavior of motor control devices is described by the
State Transition Diagram.
3.7.1. Control Supervisor Object Class Attributes
Attribute
ID
Name
Data
Type
Access
Rules
Description
Default
Value
1 Revision UINT Get Revision of this object 1
2 Max instance UINT Get
Maximum instance number of an object
currently created in this class level of
the device
1
6
Max ID of
class attributes
UNIT Get
The attribute ID number of the last class
attribute of the class definition
implemented in the device.
7
7
Max ID of
instance attributes
UNIT Get
The attribute ID number of the last
instance attribute of the class definition
implemented in the device.
15
