TL-WR542G 54M Wireless Router User Guide
enable, click the Enable button. If disabled, the function of DoS protection in
Security settings will be ineffective.
Packets Statistics Interval - The default value is 10. Select a value between 5 and
60 seconds in the pull-down list. The Packets Statistic interval value indicates the
time section of the packets statistic.
Sorted Rules - here displays sort as desired.
Statistics Table:
IP Address The IP Address displayed with statistics
Packets The total amount of packets received and transmitted by the router.
Total
Bytes The total amount of bytes received and transmitted by the router.
Packets
The total amount of packets received and transmitted in the last Packets
Statistic interval seconds.
Bytes
The total amount of bytes received and transmitted in the last Packets
Statistic interval seconds.
ICMP Tx
The total amount of the ICMP packets transmitted to WAN in the last
Packets Statistic interval seconds.
UDP Tx
The total amount of the UDP packets transmitted to WAN in the last
Packets Statistic interval seconds.
Current
TCP
SYN Tx
The total amount of the TCP SYN packets transmitted to WAN in the last
Packets Statistic interval seconds.
Click the Save button to save the Packets Statistic interval value.
Click the Auto-refresh checkbox to refresh automatically.
Click the Refresh button to refresh immediately.
