9 4300 Series Overview
The 4300 Series UPS and ancillary cabinets have been specifically designed for line-up-and-match
installations. The optional Transformer/Switching Cabinet, Battery Cabinet, and MBS Cabinet have been
designed with a pleasing aesthetic look in IT black, while occupying a minimal footprint for the delivered
capacity and capability.
The ancillary units should be installed in the relative order shown below. .
The electrical connections between the 4300 Series system components is show in Figure 9-2
Figure 9-1 - 4300 Series System Assembly
Toshiba Battery Cabinet
4300 UPS
Maintenance Bypass Switch
(MBS Cabinet)
Toshiba Auxiliary Cabinet
