NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 6
FIREPLACE SPECIFICATIONS
Figure 11
17 1/2"
(445mm)
32 7/8"
(835mm) 21"
(533m)
6"
(152mm)
40 1/2"
(1029mm)
37 3/8"
(949mm)
42 3/4"
(1086mm)
38 5/8"
(981mm)
17 1/2"
(445mm)
32 7/8"
(835mm) 21"
(533m)
6"
(152mm)
40 1/2"
(1029mm)
37 3/8"
(949mm)
42 3/4"
(1086mm)
38 5/8"
(981mm)
10"
(254mm)
40 1/4"
(1022mm)
10 1/2"
(267mm)
7 1/2
(191mm)
40 1/4"
(1022mm)
19 7/8"
(505mm)
10"
(254mm)
35"
(889mm)
15"
(381mm)
42 3/4"
(1086mm)
10"
(254mm)
24"
(610mm)
Right Corner Opening
Closed End
Left Corner Opening
Open End
Top View
For Canadian Installations
Proceed with Steps 4 through 7.
Step 4. Attach the chimney collar enclosure kit,
Model CCK1, around chimney collar with the
screws provided (
Figure 10 ).
Figure 10
Step 5. Connect the 4" (102 mm) Class 0 air
duct provided to the collar on the chimney
collar enclosure with the screws provided in the
hardware kit.
IMPORTANT: UNDER NO CIRCUMSTANCES
CAN THE FIREPLACE TOP SPACERS (
FIGURE
6 ) BE REMOVED OR MODIFIED, NOR MAY
YOU NOTCH THE HEADER TO FIT AROUND
OR BE INSTALLED LOWER THAN THE SPAC-
ERS. THE HEADER MAY BE IN DIRECT CON-
TACT WITH THE TOP SPACERS BUT MAY NOT
BE SUPPORTED BY THEM.
Note: The framed depth, 21 ³⁄₄" (552 mm) from
a framed wall, must always be measured from
a finished surface. If a wall covering such as
drywall is to be attached to the rear wall, then
the 21
³⁄₄" (552 mm) must be measured from
the drywall surface. It is important that this
dimension be exact.
If the appliance is to be elevated above floor
level, a solid continuous platform must be
constructed.
The header may rest on the top metal spacers,
but must not be notched to fit around them.
Consult all local codes.
Enclosure
Box
