11.3.2 Pin Assignment
The following table describes all of the pins on the Task File Interface.
Table 11.3-1 Signal pin assignment
PIN No.
SIGNALS
PIN No.
SIGNALS
1 -
RESET
2
GROUND
3
DD 7
4
DD 8
5
DD 6
6
DD 9
7
DD 5
8
DD 10
9
DD 4
10
DD 11
11
DD 3
12
DD 12
13
DD 2
14
DD 13
15
DD 1
16
DD 14
17
DD 0
18
DD 15
19 GROUND
20
OPEN
21 DMARQ
22
GROUND
23 -
DIOW
24
GROUND
STOP
25 -DIOR
26
GROUND
-DMARDY
HSTROBE
27 IORDY
28
CSEL
-DMARDY
-DSTROBE
29 -DMACK
30
GROUND
31 INTRQ
32
-
IOCS16
33
DA 1
34
- PDIAG
-CBLID
35
DA 0
36
DA 2
37
- CS0
38
- CS1
39 -
DASP
40
GROUND
41
+ 3.3V
42
+ 3.3V
43 GROUND
44
RESERVED
Note) Symbol (-) in front of signal name shows negative logic.
