Understanding the Drive LEDs
This chapter describes the LEDs on the front panel of the DDS-4 and DAT 72 drives. These LEDs pro-
vide information about both normal and error conditions.
Topics in this chapter are:
• “Front Panel LEDs” on page 46
• “LED Summary” on page 47
• “Clean LED” on page 47
• “Media LED” on page 48
• “Drive LED” on page 48
Front Panel LEDs
Figure 16 on page 46 shows an example of the LEDs on the drive front panel of the DDS-4 and DAT
72 drives. The external tape drive has the same front-panel LEDs, plus a green Power-On LED.
FIGURE 16. Front Panel LEDs on Internal Drive (external drive is similar)
