Front & Rear Panels —Continued
O ZONE 2 LINE OUT (79)
This analog audio output can be connected to a line
input on an integrated amplifier in Zone 2.
P DVD IN
Here you can connect a DVD player. Input jacks
include S-Video, composite video, and analog
audio. You can connect a DVD player’s 2-channel
analog audio output or 7.1-channel analog audio
output.
Q VIDEO 1 IN/OUT
Here you can connect a VCR. Input and output
jacks include S-Video, composite video, and analog
audio.
R VIDEO 2 IN/OUT
Here you can connect a VCR. Input and output
jacks include S-Video, composite video, and analog
audio.
S VIDEO 3 IN
Here you can connect a video source (VCR, set-top
box, etc.). Input jacks include S-Video, composite
video, and analog audio.
T TAPE IN/OUT
This analog audio input and output are for connect-
ing a recorder with an analog audio input and output
(cassette, Mini Disc, etc.).
U CD IN
This analog audio input is for connecting a CD
player’s analog audio output.
V COMPONENT VIDEO OUT
This component video output can be used to con-
nect a TV or projector with a component video
input.
W COMPONENT VIDEO IN 1, 2, 3
These component video inputs can be used to con-
nect AV components with component video outputs,
such as DVD players.
X REMOTE CONTROL
This (Remote Interactive) jack can be con-
nected to an jack on another Onkyo AV compo-
nent. The AV receiver’s remote controller can then
be used to control that component. To use
, you
must make an analog audio connection (RCA)
between the AV receiver and the other AV compo-
nent, even if they are connected digitally.
See pages 18-36 for connection information.
