Flash modes: Auto Flash (automatic flash activation in low-light,
backlight and fluorescent light), Red-Eye Reduction
Flash (same as auto otherwise), Flash-Off (flash
override with shutter speed extended to 2-sec. max.),
Fill-In (forced activation), Night Scene flash (with
shutter speed extended to 4-sec. max.) and Red-Eye
Reduction Night Scene Flash (with shutter speed
extended to 4-sec. max.)
Exposure modes: Auto Exposure, Spot Metering, Backlight Compensation
and Infinity.
Battery check: Displayed on LCD panel.
Power source: One 3 V lithium battery (CR2).
Dimensions: 101 (W) x 57 (H) x 42 (D) mm (4.0 x 2.2 x 1.7 in).
Weight: 210 g (7.4 oz) (without battery) .
Other: All-weather design.
࡯ Date Unit Specifications (Quartzdate model)
Types of data recording:
(1) None. (2) Year-month-day. (3) Month-day-year.
(4) Day-month-year. (5) Day-hour-minute.
External display of recorded data:
Continuous LCD panel display.
Automatic calendar function:
To year 2035.
࡯ Remote Control Specifications (Optional)
Remote control system:
Infrared.
Power source: One CR2025 battery.
Battery life: Approx. 5 years.
Usage: Approx. 20,000 times.
Working distance: Approx. 5 m (16.4 ft).
Dimensions:
56.5 (W) x 35.0 (H) x 6.5 (D) mm (2.2 x 1.4 x 0.3 in).
Weight: 11 g (0.4 oz) (without battery).
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE OR
OBLIGATION ON THE PART OF THE MANUFACTURER. THE ACTUAL
PRODUCT MAY DIFFER FROM ONES SHOWN IN THIS MANUAL.
SPECIFICATIONS
Type: Fully automatic 35 mm autofocus lens-shutter
camera with built-in 38 ~ 105 mm zoom lens.
Film format: 35 mm standard DX-coded film (24 x 36 mm).
Lens: Olympus lens, 38 ~ 105 mm, F5.6 ~ 11.3, 8 elements
in 7 groups.
Shutter: Programmed electronic shutter.
Viewfinder: Real image zoom viewfinder [with autofocus marks,
close-up correction marks, green lamp (autofocus
indicator) and orange lamp (flash indicator)].
Focusing: Multi-wide advanced combination autofocus system
(max. 11 points). Focus lock possible. Focusing
range: 0.6 m (2.0 ft) ~
∞ (infinity) at telephoto, 0.8 m
(2.6 ft) ~ ∞ (infinity) at wide angle.
Exposure control: Programmed automatic exposure control, 3-zone
light metering. Auto exposure range: EV3 (F5.6, 4-
sec) ~ EV16 (F10.8, 1/570-sec) at wide angle, EV5
(F11.3, 4-sec) ~ EV17 (F17, 1/430-sec) at telephoto.
Exposure counter: Progressive type displayed on LCD panel.
Selftimer:
Electronic selftimer with approx. 12-sec. delay.
Remote control: Infrared remote control unit with approx. 3-sec.
delay.
Film speed range: Automatic setting with DX-coded film (ISO50, 100,
200, 400, 800, 1600 or 3200). Other intermediate
film speeds will be automatically set for next lower
speed. Non-DX-coded film is set at ISO100.
Film loading: Automatic loading. (Automatically advances to first
frame when camera back is closed.)
Film advance: Automatic film winding.
Film rewind: Automatic film rewind (automatic rewind activation at
end of film, automatic rewind stop). Rewind possible
at any point with mid-roll rewind button.
Flash: Built-in flash. Recycling time: Approx. 0.5 ~ 6.0 sec.
(at normal temperature, with new battery). Flash
working range: 0.8 ~ 3.2 m (2.6 ~10.5 ft) at wide
angle and 0.6 ~ 1.6 m (2.0 ~ 5.2 ft) at telephoto with
ISO 100 color negative film; 0.8~ 6.4 m (2.6 ~ 21.0
ft) at wide angle and 0.6 ~ 3.2 m (2.0 ~ 10.5 ft) at
telephoto with ISO400 color negative film.
