SAFETY CONSIDERATIONS
Warning
The instructions in this User’s Manual are for use by qualified personnel only. To avoid electrical
shock, do not perform any servicing of this unit or its accessories (such as power units) other
than that contained in the operating instructions, unless you are qualified and certified to do so by
Omnitron Systems Technology, Inc.
Caution
All user-required operations can be performed without ever opening the unit’s cover. Never attempt
to open or remove the unit’s cover or tamper with its power units (other than plugging and unplugging
them as specified in the operating instructions).
Line Voltage
Before Connecting the Power units to the line voltage, make sure that the voltage of the power
source (wall outlet) matches the voltage specified on the power units.
Warranty
This OST product is warranted to the original purchaser against defects in material and
workmanship for a period of TWO YEARS from the date of shipment. This warranty period may
be extended to LIFETIME by the original purchaser if the product is REGISTERED with OST
within 90 days from the date of shipment. TO REGISTER, PLEASE COMPLETE AND MAIL OR
FAX BACK THE REGISTRATION CARD. During the warranty period,
OST will, at its option,
repair or replace a product which is proven to be defective.
For warranty service/repair, the product must be sent to an OST designated repair facility, shipment
prepaid by the Buyer. OST will pay postage/shipping charges to return the product to Buyer
(using OST’s standard shipping method).
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting from improper or inadequate use and/
or maintenance of the equipment by Buyer, Buyer-supplied equipment, Buyer-supplied interfacing,
unauthorized modifications or tampering with equipment (including removal of equipment cover
by personnel not specifically authorized and certified by
OST), misuse, operating outside the
environmental specification of the product (including but not limited to voltage, ambient temperature,
radiation, unusual dust, etc.), or improper site preparation or maintenance.
No other warranty is expressed or implied. OST specifically disclaims the implied warranties of
merchantability and fitness for any particular purpose.
Exclusive Remedies
The remedies provided herein are the Buyer’s sole and exclusive remedies. OST shall not be
liable for any direct, indirect, special, incidental, or consequential damages, whether based on
contract, tort, or any legal theory.
Form:040-02651-001 07/00
Omnitron Systems Technology, Inc. 7
SPECIFICATIONS
n Protocol: IBM 5250 and 5250 Express for systems AS/400 and 3X
n Devices Supported: All twinax/IBM compatible devices (terminals and
printers)
n Interface:
Link: One (1) Twinax, One (1) Fiber or
One (1) Rj11/45, One (1) Fiber
Port: One (1) Twinax or
One (1) Rj11/45
(RJ11 pins 3-4, RJ45 pins 4-5 are standard)
n Cable Types:
Twinax: IBM 7362229 or equivalent
UTP: Category 3 (EIA/TIA 568) or higher
(shorter distance @ lower grade)
n Data Rate:
Standard 5250: 1 Mbps -2%, +4%
5250 Express: 1 or 2 Mbps -2%, +4%
n Supported Distances:
Host/Device to Mux:
Twinax: 5,000 ft.
UTP: 3,000 ft.
Multimode fiber: 15,000 ft.
Single-mode fiber: 30,000 ft.
n Physical Dimensions:
Rackmount: W:19.0”xD:6.0”xH:1.75”
Tabletop: W:17.5”xD:6.0”xH:1.75”
n Weight: 7 lbs.
n Power: 115 or 230 VAC, 100/50 mA
n Temperature:
Operating: 0° to 40°C
Storage: -40° to 75°C
Humidity: Up to 90% (non-condensing)
TECHNICAL SUPPORT
For assistance in installing this product, contact Omnitron’s Technical Support
Department.
Phone: (949) 250-6510
Fax: (949) 250-6514
Address: Omnitron Systems Technology, Inc.
27 Mauchly #201
Irvine, CA 92618, USA
Email: [email protected]
URL: www.omnitron-systems.com
