Using the ac adapter – Omron Healthcare HEM-741CREL User Manual

Page 9

Text mode
Original mode

Use only the authorized Omron AC Adapter, (Model Number
HEM-ADPT1) with this monitor. Use of any other adapter
may cause damage to the monitor and will void the user warranty.

To connect the AC Adapter
① Insert the AC Adapter Plug into the AC Adapter Jack on the back side

of the monitor as illustrated.

② Plug the AC Adapter into a 120V AC outlet (60 cycles).

To disconnect the AC Adapter remove the AC Adapter from the electrical
outlet first and then remove the AC Adapter Plug from the monitor.

NOTE:

• We recommend batteries are installed and used with the AC

Adapter. If batteries are not installed the Date and Time must

be set each time the AC Adapter is disconnected from

the electrical outlet.

• When the AC Adapter is used, the battery life is extended.

USING THE AC ADAPTER

HEM-741REL 8-29 Final Rev 1/23/06 9:27 AM Page 9
