Remote Controller
For detailed information, see the pages in parentheses.
RECEIVER button (22)
ACTIVITIES buttons (43, 78)
REMOTE MODE/INPUT SELECTOR buttons
(
23)
SP LAYOUT button (42)
Arrow / / / and ENTER buttons
SETUP button (44)
Listening Mode buttons ( 34)
DIMMER button (40)
DISPLAY button (41)
MUTING button (42)
VOL / button (23)
RETURN button
HOME button (40, 63)
SLEEP button (40)
■
Controlling the tuner
To control the AV receiver’s tuner, press TUNER (or
RECEIVER).
You can select AM or FM by pressing TUNER
repeatedly.
Arrow / buttons ( 28)
D.TUN button (29)
DISPLAY button
CH +/– button (29)
Number buttons ( 29)
*1 When you want to change the remote controller mode (target
component) without changing the current input source, press
MODE and within about 8 seconds, press REMOTE MODE.
Then, using the same AV receiver’s remote controller, you
can control the component corresponding to the button you
pressed.
*2 These buttons can also be used when a REMOTE MODE
other than receiver mode is selected. (Pressing HOME
switches to Receiver mode.)
Controlling the AV Receiver
*1
*2
*2
*2
To control the AV receiver, press RECEIVER to
select Receiver mode.
You can also use the remote controller to control
Onkyo Blu-ray Disc/DVD player, CD player, and
other components.
See “Entering Remote Control Codes” for more
details (
➔
page 74).
