Page 10
10
En
DIGITAL IN COAXIAL and OPTICAL jacks
RS232 port
Terminal for control.
REMOTE CONTROL jack
USB port
UNIVERSAL PORT jack
ETHERNET port
HDMI IN and HDMI output (HDMI OUT MAIN and
HDMI OUT SUB) jacks
MONITOR OUT V and S jacks
COMPONENT VIDEO IN and MONITOR OUT
jacks
IR IN and OUT jacks
ZONE 2 and ZONE 3 12V TRIGGER OUT jacks
FM ANTENNA jack and AM ANTENNA terminal
PC IN jack
AC INLET
GND screw
Composite, S-Video and analog audio jacks
(
BD/DVD IN, VCR/DVR IN and OUT, CBL/SAT
IN, GAME IN, PC IN, TV/CD IN and PHONO IN)
Multichannel input jacks
(
FRONT L/R, CENTER, SURR L/R, SURR BACK
L/R and SUBWOOFER)
PRE OUT jacks
(
FRONT L/R, CENTER, SURR L/R, SB/FH/FW
*
,
SUBWOOFER)
*
SB···Surround Back, FH···Front High, FW···Front Wide
ZONE 2 and ZONE 3 PRE/LINE OUT jacks
Speaker Terminals
(
FRONT L/R, CENTER, SURR L/R,
SURR BACK L/R, FRONT HIGH L/R and FRONT
WIDE/ZONE 2 L/R)
Rear Panel
