Page 7
User’s Manual Series DRF
4-SIGNAL INPUT JUMPERS___________________________________
The position of the input jumpers selects the
range for the input signal as indicated below.
J7
J8
J9
J10
J11
J12
J7
J8
J9
J10
J11
J12
10 KOhms 1,5 KOhms 3 KOhms 5 KOhms
50% 100%
J7
J8
J9
J10
J11
J12
25%
J7
J8
J9
J10
J11
J12
12.5%
DRF-POT Input signal ranges for
Potentiometer measure
DRF-RES Input signal ranges for
Resistance measure
