User’s Manual Series DRF
3-DIMENSIONS AND CONNECTIONS____________________________
H
OUSING WIDTH FOR
AC
POWERED
INSTRUMENTS
Output Connections
Input Connections
9mm
(0.35’’)
93mm
(3.66’’)
22.5mm (0.87’’)
DC P
OWERED
C
ONNECTIONS
110 mm
(4.33’’)
24 V
DC
AC P
OWERED
C
ONNECTIONS
~
~
3 2 1
0 V
DC
37mm (1.46’’)
C
ONNECTIONS FOR
P
OTENTIOMETER
C
ONNECTIONS FOR
R
ESISTANCE
C ABLE
S HIELD
