2 Operating Functions
4
Handset
1
Redial button
2 Memory button
3 Store button
4 Recall button
5 Earpiece volume level control
6 Ringer adjustment switch
7 Connection for curly handset cord
Telephone base unit
8
Radio FM/AM button
9 Up/Hour button
10 Down/Min button
11 Power LED
12 Snooze button
13 LCD display
14 Message lamp
15 Radio LED
16 Radio On/Off button
17 Time Set button
18 Alarm Set button
19 Hook switch
20 Radio volume
Rear of the telephone base unit
power connection
FM antenna
Radio/Buzzer alarm switch
Connection for handset curly cord
Telephone cable connection
Lower surface of the telephone
Battery compartment
Inside battery compartment
Message waiting switch (PBX use only)
1
3
2
4
5
6
8 9 10
11
12 13 14 15 16 18
17
19 20
7
