56
Specification
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
Power Output
2 channel driven:
North American: 100 W + 100 W
(8
Ω, 1 kHz, FTC)
European: 100 W + 100 W
(8
Ω, 1 kHz, DIN)
Asian: 120 W + 120 W (8 Ω, 1kHz, JEITA)
Dynamic Power 230 W + 230 W (3 Ω, Front)
170 W + 170 W (4 Ω, Front)
115 W + 115 W (8 Ω, Front)
THD (Total Harmonic
Distortion)
0.08% (Power Rated)
Damping Factor 60 (Front,1kHz,8 Ω)
Input Sensitivity and
Impedance
200 mV/ 47 k Ω (LINE)
Output Level and
Impedance
200 mV/ 470 Ω (REC OUT)
Frequency Response 10 Hz–100 kHz/ +1 dB-3 dB (Direct
mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 8 Ω– 16Ω
Input Sensitivity/Output
Level and Impedance
1 Vp-p /75 Ω(Composite)
Tuning Frequency
Range
North American: 87.5 MHz– 107.9 MHz
European: 87.5 MHz– 108.0 MHz
Asian: 87.5 MHz– 108.0 MHz
Usable Sensitivity Stereo:17.2 dBf 2 µV(75 Ω IHF)
Mono: 11.2 dBf 1 µV(75 Ω IHF)
Signal to Noise Ratio Stereo: 70 dB (IHF-A)
Mono:76 dB (IHF-A)
THD Stereo: 0.3% (1kHz)
Mono:0.2% (1kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 45 dB (1kHz)
Tuning Frequency
Range
North American: 530 kHz–1710 kHz
European: 522 kHz–1611 kHz
Asian: 530/522 kHz–1710/1611 kHz
Usable Sensitivity 30 µV
Signal to Noise Ratio 40 dB
THD 0.70%
Power Supply North American: AC 120 V, 60 Hz
Australian and European:
AC 230-240 V, 50 Hz
Others: AC 120/220-240 V, 50/60 Hz
Power Consumption North American: 5.5 A
Others: 380 W
Stand-by Power
Consumption
North American: 0.1 W
European: 0.2 W
Others: 0.5 W
Dimensions
(W
×
H
×
D)
435
Ч
150
Ч
369 mm
17-1/8"
Ч
5-7/8"
Ч
14-1/2"
Weight North American and European: 8.8 kg
19.4 lbs.
Others: 9.6 kg, 19.0 lbs.
Composite DVD,VIDEO1,VIDEO2,VIDEO3
Composite MONITOR,VIDEO1
Digital Inputs Optical: 1
Coaxial: 1
Analog Inputs DVD(MULTICHANNEL),VIDEO1,
VIDEO2,VIDEO3,TAPE,CD
Multichannel Inputs 6
Analog Outputs TAPE,VIDEO1
Speaker Outputs SP-A (L, R, C, SL, SR, SW) + SP-B (L, R)
Phones 1
