Introduction
Omega Engineering OMG-ULTRA COMM+2.PCI Page 1
Introduction
Overview
The OMG-ULTRA COMM+2.PCI is a two channel PCI Bus serial I/O adapter for
the PC and compatibles. It provides two field selectable RS-232/422/485 serial
ports supporting data rates up to 460.8K bps.
Configure both ports as RS-232 for standard serial COM: port requirements.
Choose the RS-422 mode for long distance device connections up to 4000ft.
where noise immunity and high data integrity are essential. Select RS-485 and
capture data from multiple peripherals in a RS-485 multidrop network. Up to 31
RS-485 devices can be connected to each port to automate your data collection.
You can even mix the ports in any of the interface combinations to provide
maximum flexibility to your application.
In both RS-232 and RS-422 modes, the card works seamlessly with the standard
operating system serial driver. In RS-485 mode, our special auto-enable feature
allows the RS-485 ports to be viewed by the operating system as a COM: port.
This allows the standard COM: driver to be utilized for RS-485 communications.
Our on-board hardware automatically handles the RS-485 driver enable. UART
upgrades are available providing 32 and 64 byte FIFOs.
What’s Included
The OMG-ULTRA COMM+2.PCI is shipped with the following items. If any of
these items are missing or damaged, contact the supplier.
•
OMG-ULTRA COMM+2.PCI Serial I/O Adapter
•
Serial Utility Software
•
User Manual
Factory Default Settings
The OMG-ULTRA COMM+2.PCI factory default settings are as follows:
Port # Electrical Specification
Port 1 RS-232
Port 2 RS-232
To install the OMG-ULTRA COMM+2.PCI using factory default settings, refer
to Installation on page 10.
For your reference, record installed OMG-ULTRA COMM+2.PCI settings below:
Port # Electrical Specification
Port 1
Port 2
